Vacuum Casting Service

Vacuum Casting • From 1 to 50+ Parts • Can be delivered Globally

Our company can both making first prototype and casting copies based on your CAD designs or other information. We can provide you not only best-quality molds but also all kinds finishing services including painting, sanding, pad printing and more. We can help you make a real part for showroom presentation , engineering test samples, business marketing and other purpose.

What Is Vacuum Casting?

Vacuum Casting is a kind of manufacturing method based on prototype. It works like this : according to the original sample, to make the silicone mold under vacuum ,and pouring PU material into the mold so as to clone the same copy with the original sample.

Advantages Of Vacuum Casting

01.

Cheap

02.

Easy to make molds

03.

A lot of material can be used

04.

Product “100%” copy

05.

One molds can make 15 or more copies

06.

Suitable for rapid prototypes in various industry

Why choose Vacuum Casting?

Silicone molding results in high-quality parts comparable to injection-molded components. This makes vacuum cast models suitable for fit and function testing, marketing purposes or a small quantity final parts. Vacuum Casting also lends itself well to a variety of finishing degrees, and we can match the finish you need for your parts.

Ideal applications for Vacuum Casting

Pre-production testing

Small series of housings and covers

Concept models and prototypes

Technical Specifications

Standard lead time

Up to 10 copies within 15 working days

Standard accuracy

±0.3% (with a lower limit on ± 0.3 mm on dimensions smaller than 100 mm)100mm

Minimum wall thickness

To ensure that the mold is filled properly, a wall thickness of at least

0.75mm is necessary. For best results, we recommend a wall thickness

of at least at 1.5 mm

Maximum part dimensions

The size of the mold is limited by the dimensions of the vacuum

chamber (1900x 900 x 750 mm) and by the volume of the

product (maximum volume: 10 liters)

Typical quantities

Up to 15 copies per mold (depending on the mold’s complexity

and the casting materials)

Surface structure

High-quality surface finish comparable to injection molding
